High-intensity mixing element for demanding compounding applications
Maximum mixing performance
Strong shear and cutting effect
Intensive material recombination
Suitable for difficult dispersion systems
ZME mixing screw elements are designed from a single-flight reverse conveying element with a small pitch, onto which forward-oriented teeth are introduced along the flight geometry.
This structural modification combines the reverse conveying base with forward cutting features, enabling repeated material deformation, cutting and recombination as the melt passes through the element. As a result, both dispersive and distributive mixing are achieved.
Among all mixing elements, ZME delivers the highest mixing intensity and energy input.
Provides both dispersive and distributive mixing.
Breaks agglomerates effectively.
Suitable for difficult-to-process materials.
Enhances material homogenization.
Shear + geometric disruption = maximum mixing efficiency
| Diameter | Ø18–Ø400 |
| Do/Di Ratio | 1.55～1.8 |
| Length | 0.5～2.5D |
| Pitch | Customized |
| Material | N00/D2/D11/W6/H9/H10/H26/Hastelloy/Stainless |
| Surface Hardness | HRC 58–64 |
| Max. Operating Temp | ≤450°C |
| Wear Resistance | Standard/High/Ultra-high |
| Corrosion Resistance | Standard/High/Ultra-high |
| Application | Masterbatch/Compounding/Recycling /Film/Feed/Food/Pharmacy |
| Suitable for | Twin Screw Extruder |
A: When maximum mixing intensity is required for difficult materials.
Get a Quote
CKE elements combine conveying and mixing functions, providing gentle material exchange with low shear and reduced energy consumption.
Best suited for:
Heat-sensitive materials
Low-shear compounding processes
Applications requiring stable conveying with mild mixing
TME elements use intermeshing toothed discs to split and recombine melt flow, achieving efficient distributive mixing without conveying.
Best suited for:
Melt mixing zones
Fiber-reinforced materials
High homogeneity requirements
SME elements introduce shallow reverse grooves on conveying flights, generating controlled melt backflow and improving distributive mixing.
Best suited for:
Melt stage mixing
General distributive mixing
Applications requiring good self-cleaning
